Light weight and very flexible Polyurethane hose, flame retardant

flame-retardant, permanently antistatic (R < 10⁹ Ohm), hydrolysis & microbe resistant, excellent flexibility, good oil & petrol resistance

Technische Daten

Applications: venting; wood dust extraction; automation technology & robotics; extractions arms; dust extraction; sawing & milling; extraction systems; textile fiber extraction; furniture production
Article Number: 24300025-1000-000-00
Bending Radius (mm): 15
Discharge Capability (Standard): discharge capability according to BGI 739-2 with spiral earthing
Electrical Conductivity (Standard): ATEX 2014/34/EU / pneumatic transport of combustible dusts (inside: zone 20, 21, 22) TRBS 2153/TRGS 727
Fire Protection Standard: flame-retardant according to DIN 4102 / B1
Hose Construction: spiral hose / film hose
Industries: Energy & Waste; Air conditioning, Ventilation & Extraction; Wood & Timber
Inner Diameter (mm): 25
Length (m): 10
Max. Operating Pressure (bar): 0,65
Medium: dust; air & gas
Special Properties: microbe resistant; hydrolsis resistant; flame-retardant; very smooth inside; discharge capability if spiral - strand is grounded; abrasion resistant; Made in Germany; permanently antistatic
Spiral Hose Standard: DIN 26057-1
Temperature (°C) Max.: 100
Temperature (°C) Min.: -40
Total Weight per Piece (kg): 1,39
Vacuum Max. (bar): 0,30
Wall Material (Inner Layer): TPU / Polyether-Polyurethane
Wall Thickness (mm): 0,40
